04‑08 Ford F150 4WD Fabtech K2003DL 6″ Performance System w/ Dirt Logic 2.5 Coilovers & Rear Dirt Logic Shocks

The Fabtech K2003DL is a premium 6″ suspension lift system that transforms a 2004–2008 Ford F‑150 4WD into an aggressive off‑road powerhouse without sacrificing daily comfort. Featuring Dirt Logic 2.5″ adjustable stainless steel coilovers up front and 2.25″ Dirt Logic rear shocks, it delivers exceptional damping performance, offering a compliant highway ride while handling the rigors of off‑road terrain. Built with heavy‑duty components—including nickel‑plated large‑diameter bodies and billet aluminum ends—this take‑apart design allows for fine‑tuning dampening preferences. It’s a complete kit that retains factory control arms and steering links, requires no driveshaft modifications, and is engineered for fast, no‑weld installation.

Drivers gain elevated ground clearance and enhanced caster control while maintaining stock wheel and tire compatibility. With a reputation for rugged reliability and ride quality, this lift system ensures thrilling performance on‑ and off‑road.

Key Features

• Complete 6″ lift kit with Dirt Logic stainless steel shock technology

• Front coilovers: 2.5″ OD bodies, 2.25″ pistons, nickel‑plated steel, billet aluminum end caps, take‑apart design

• Rear shocks: Dirt Logic 2.25″ stainless steel heavy‑duty dampers

• Heavy‑duty ¼″ steel lower control arm cross‑members with integrated diff skid plate

• Extended‑length ductile‑iron steering knuckles allowing 18″–22″ wheels

• Retains factory steering links & UCA; no driveshaft modification for Auto‑Trac

• Quick, no‑drill, no‑weld installation

• Compatible with stock tires and wheels

Benefits

• Superior off‑road capability: Long‑travel coilovers absorb harsh terrain for better control

• Balanced ride quality: Street‑smooth handling without harshness

• Improved steering precision: Increased caster and factory geometry retention

• Durable construction: Heavy‑duty steel and stainless hardware built to last

• Easy upkeep: Serviceable design means coilover rebuilds or tuning are possible

• Warranty support: Backed by Fabtech’s 5‑year/60,000‑mile powertrain suspension warranty

Product Specs

• Lift height: 6 inches

• Front coilover body: 2.50″ OD nickel‑plated steel

• Front piston size: 2.25″ OD

• Rear shocks: 2.25″ Dirt Logic stainless steel

• Cross‑member: ¼″ heavy‑duty steel

• Steering knuckles: Extended ductile iron

• Color: Stainless steel finish (coilovers), black hardware

• Material: Steel, stainless steel, billet aluminum

• Compatibility: Fits stock tires and wheels; allows 18″–22″ rims

Install Difficulty Level

This kit installs in approximately 4 hours, with zero drilling or welding required. The bolt‑on, no‑cut components make installation straightforward and accessible—even for DIYers with basic tools—while saving time on alignment.

Vehicle Fitment

Fits 2004‑2008 Ford F‑150 4WD models (all engines). This kit is engineered specifically for these years to ensure accurate suspension geometry, vehicle dynamics, and tire fitment.

Any questions about fitment, install tips, or to report inaccuracies in this description, contact the MPT Performance experts at (407) 636‑7077 or by email.
